Product Description

Karcher’s fully hydraulic KM150/500 R sweeper can be perfectly tailored to meet the needs of your business. Choose LPG or diesel power; indoor or outdoor protective cabs; and a wide range of accessories. Fantastic build quality, incredible productivity and fully hydraulic controls all come as standard. The choice of power options make it very versatile for use in different areas from public road to cleaning of noise sensitive areas indoors. Thanks to the dustpan principle, fine sweepings and coarse dirt are reliably vacuumed. The roller brush automatically adjusts to uneven surfaces and the innovative sweeping system reduces wear and tear to a minimum. The main roller brush can be easily changed without tools. The waste container automatically closes during transport. Two horizontally installed flat pleated filters ensure clean air under heavy dust conditions. Filter cleaning can be done with the push of a button using a highly effective dual scraper. The filter is easily accessible and can be cleaned or changed without the need for tools. The engine is also easy to access.

Features and benefits
Efficient filter system
  • Flat pleated filter with 7 m² filter area.
  • Effective cleaning with dual scraper.
  • For dust-free sweeping.
Comfortable workplace
  • All controls are clearly arranged and easy to access.
  • All displays in full view.
  • Optional: cabs with heating or air-conditioning.
Diesel operation
  • Designed for continuous use.
  • Powerful motorisation
Optional four-wheel chassis
  • Improves traction on slippery and uneven surfaces.
  • Increases ride comfort and driving safety.
  • Ideal for use on sensitive surfaces due to low surface pressure.
Hydraulic container lift
  • Emptying the waste is safe and easy.
  • High dump system up to 1.52 m.
Dustpan principle
  • Good intake of fine and coarse waste.
  • Low dust dispersion.
Comprehensive range of accessories and attachment kits
  • Easy adaptation to individual cleaning needs.
  • Impressive equipment (e.g. comfort cab, air-conditioner, heating).
  • Second and third side brushes available on request.
Fully hydraulic traction drive and driven main sweeper roller and side brush
  • Extremely low-maintenance.
  • No wear and tear.
  • Extremely durable.
Cyclone pre-filter
  • Longer working time for the motor filter.
  • Extended maintenance intervals.
Specifications

Technical data

Drive 4-stroke diesel engine / Yanmar
Drive – power (kW) 22.5
Drive type Diesel
Max. area performance (m²/h) 18000
Working width (mm) 1200
Working width with 1 side brush (mm) 1500
Working width with 2 side brushes (mm) 1800
Waste container (l) 500
Hill climbing ability (%) 18
Operating speed (km/h) 12
Filter area (m²) 7
Weight (kg) 1440
Dimensions (L x W x H) (mm) 2442 x 1570 x 1640

Equipment

  • Manual filter cleaning system
  • Traction drive, hydrostatic
  • Adjustable roller brush
  • Power steering
  • Adjustable suction power
  • Dustpan principle
  • Travel drive - forward
  • Travel drive, reverse
  • Vacuum
  • Hydraulic container lift
  • Outdoor applications
  • Operating hour meter
  • Sweep function (can be switched off)
  • Pneumatic wheels
  • Side brush swings out automatically

Specifications

Origin
1.186-124.0
EAN
4039784521902
GTIN
4039784521902
ORIGIN
IT
Customs Tariff
84798997
Size
2650 x 1650 x 1700
MPN
1.186-124.0
Brand
Karcher
Condition
New
Product Code
11861240
Weight
1555kg

Customer Reviews

Karcher KM 150/500 R D

Product Code 11861240

**Onsite Warranty and Full Onsite Training included**
