Karcher High-pressure washer HD 9/18-4 St USED UNIT

The configurable HD 9/18-4 ST, with a power of 180 bar and 900l/h, is the all-round solution from Karcher in the area of cold water stationary machines for single-lance operation

The particular strength of the new generation of Karcher cold water high-pressure cleaners is that they can be individually configured. This means that buyers only pay for precisely the equipment features which are really needed. Individual details can be easily retrofitted at a later date on request. The equipment features available include: A hot water version, which when configured to STH spec can be operated with a maximum input temperature of 85°C. A stainless steel casing for hygienically sensitive areas. Pressure relief to increase the service life. Dry running protection. Water softening for an especially hot water supply. An operating hour counter for efficient servicing. One or two cleaning agent suction option in high or low pressure use. Thanks to a wide range of accessories, the supply points can be specifically adapted to the cleaning task on site. Various remote controls, hose guide systems or a coin remote control are available. As individual as it gets!

This unit has benefitted from a full pump overhaul.

Features and benefits

Application-based configuration

• You don't pay for anything that isn't really needed.
• Simply choose a basic unit and add only the required functions.
• Extensive range of accessories for a wide range of applications.

High flexibility

• Further accessory parts or equipment can be attached.
• Remote controls can be used directly at the point of use.
• Simple pre-connection of a HWE 860 hot water generator possible.

Is ready for use quickly at any time

• The pump starts as soon as the trigger gun is activated, allowing convenient working from any supply point.
• Ready at the push of a button, with no set-up times or transporting mobile machines.
• For fast cleaning at different locations of use.

Durable and robust design

• Suitable for daily use.
• Allows long periods of use and increases efficiency and productivity.
• Minimal maintenance effort and long lifetime.

Always flexible thanks to fast retrofitting capability

• Most functions and accessory parts can be retrofitted at any time.
• Simple Plug-and-Play saves assembly costs.
• Adjustment to changed requirements instead of a new purchase.

Perfectly hygienic

• Up to 70°C water supply temperature even in the basic model.
• Advance pressure pump for inlet temperature of up to 85°C.
• Simple pre-connection of a HWE 860 hot water generator possible.

Durable and robust

• 4-pole, slow-running electric motor guarantees a long working time.
• Robust brass cylinder head and ceramic piston.
• 4-pole electric motor with 3-piston axial pump.

Most equipment features and accessory parts can easily be retrofitted at any time

• The extensive accessory line provides for ergonomic and economical cleaning solutions for numerous applications.
• The needs-based equipment and compatible accessories for every installation location and every budget.
• Minimum installation effort.

Specifications

Technical data

Supply voltage (Ph/V/Hz)	3 / 400 / 50
Flow rate (l/h)	460 - 900
Working pressure (bar/MPa)	40 - 180 / 4 - 18
Max. pressure (bar/MPa)	200 / 20
Inlet temperature (°C)	70
Connected load (kW)	6,8
Protection (A)	16
Water inlet	1″
Number of users	1
Portability	Stationary
Weight (with accessories) (kg)	62,5
Dimensions (L x W x H) (cm/mm)	533 / 420 x 790

Equipment

• Spray gun: EASY!Force Advanced
• High-pressure hose: 10 m, ID 8, 315 bar
• Triple nozzle (0°/ 25°/40°): manual
• Stainless steel spray lance: 1050 mm
• Dry-running protection
• Elapsed time counter
• Prepared for remote control
• Prepared for servo control
• Pre-equipped for a detergent inlet
