Product Description

Karcher High-pressure washer HD 9/20-4 S

The Karcher HD9/20-4 S Classic cold water high-pressure cleaner delivers high power and Super Class quality – its ergonomic design makes it the ideal tool for daily use.

The Karcher HD 9/20-4 S cold water high-pressure cleaner is ideal for daily use in tough conditions. The finest materials guarantee top quality – and you can count on both from Karcher. Inside the machine, a hard-wearing wobble pump with stainless steel pistons and a brass cylinder head delivers powerful performance, complemented by a 4-pole low-speed motor with air-water cooling system. Integrated aluminium frame carriers reduce the weight and provide a light yet hard-wearing chassis, suitable for crane loading. For a compact design and maximum portability, the motor and pump unit is mounted vertically in an upright arrangement. In addition to this, it features accessory storage in the form of a stowage compartment and adjustable hooks. The HD9/20-4 S takes ergonomic working to the next level. Thanks to the EASY!Force Advanced trigger gun, it can be operated effortlessly without any holding force, ably assisted by a rotating 1050-millimetre stainless steel lance. The Servo Control controller positioned between the trigger gun and lance can be used to adjust pressure and water volume.

Features and benefits
High-pressure washer HD 9/20-4 S: Compact upright design concept based on vertical arrangement of motor and pump unit
Compact upright design concept based on vertical arrangement of motor and pump unit
Small footprint and space-saving proportions. Easy to manoeuvre and transport. Maximum stability ensures a stable footing for the machine.
High-pressure washer HD 9/20-4 S: 4-pole low-speed motor with air-water cooling system, robust pump with stainless steel pistons and brass cylinder head
4-pole low-speed motor with air-water cooling system, robust pump with stainless steel pistons and brass cylinder head
Long service life and low maintenance costs. High performance and high efficiency. With suction feature and up to 60 °C water temperature.
High-pressure washer HD 9/20-4 S: Intelligently designed service concept facilitates quick operations on site
Intelligently designed service concept facilitates quick operations on site
Swivelling pump head. Convenient oil fill level display and oil drain hole integrated in the chassis. Modular construction, comprising pump, motor and control cabinet.
Wide-ranging accessories with EASY!Lock
  • Pressure and water volume can be adjusted on the Servo Control controller positioned between the lance and trigger gun.
  • EASY!Force Advanced for fatigue-free work without any holding force.
  • Rotating 1050 mm stainless steel lance.
Multiple storage spaces for accessories integrated into the machine
  • Stowage compartment.
  • Adjustable hooks, e.g. for storing second lance or electric cable.
  • Storage for high pressure hose.
Specifications

Technical data

Supply voltage (Ph/V/Hz) 3 / 376 - 424 / 50
Flow rate (l/h) 500 - 900
Inlet temperature (°C) 60
Working pressure (bar) 50 - 200
Max. pressure (bar) 250
Connected load (kW) 7
Power cable (m) 5
Nozzle size 047
Water inlet 1″
Weight (with accessories) (kg) 62,4
Weight incl. packaging (kg) 71,5
Dimensions (L x W x H) (mm) 607 x 518 x 1063

Scope of supply

  • Spray gun: EASY!Force Advanced
  • Spray gun with soft grip padding
  • High-pressure hose: 10 m, Premium quality, ID 8, 315 bar
  • Spray lance: 1050 mm
  • Power nozzle
  • High-pressure spray lance
  • Servo control

Equipment

  • 4-pole, three-phase motor with air and water cooling
  • 3-piston axial pump: With stainless steel pistons
  • Pressure switch-off
  • Integrated water fine filter
  • Oil level indicator
  • Brass water inlet
High-pressure washer HD 9/20-4 S
High-pressure washer HD 9/20-4 S
High-pressure washer HD 9/20-4 S
High-pressure washer HD 9/20-4 S
High-pressure washer HD 9/20-4 S
High-pressure washer HD 9/20-4 S
High-pressure washer HD 9/20-4 S
High-pressure washer HD 9/20-4 S


Specifications

MPN
1.286-951.0
GTIN
4054278904269
EAN/UPC
4054278904269
Country of Origin
DE
Customs Tariff
84243008
Size
1194 x 570 x 623
Brand
Karcher
Condition
New
Product Code
12869510
Weight
71.461kg

Customer Reviews

Karcher HD 9/20-4S

Product Code 12869510

Two Year Warranty and Full onsite Training included in delivery charge
