Product Description

The Karcher IV100/55 M B1 three phase industrial vacuum is especially developed to handle dusts of the dust explosion classes ST1, ST2 and ST3 in zone 22. It is designed to pick up liquids and oils as well as dry material such as dust and dirt. Simple to operate, this vacuum uses advanced technology which delivers a long service life, high productivity all at low running costs. With a 100 litre container capacity and a variety of special purpose accessories, the machine is ideal for a broad range of cleaning applications in industry, particularly in the metalworking and plastics industries. The single motor runs from a three-phase power supply and is designed for continuous duty. Depending on the application, container (dry) part-no. 6.394-527.0 or container (wet) part-no. 6.394-529.0 needs to be ordered separately.

Features and benefits

Convenient storage area for accessories on the machine's chassis	Large accessory basket on the machine chassis offers a convenient storage space for nozzles, bends and other parts.
Manual filter vibration for low operating costs	The manual filter vibration increases the working time of the permanent filter, thereby reducing the maintenance effort.
Resilient and versatile	The extensive accessory line provides for ergonomic and economical cleaning solutions for numerous applications.
Waste container with set-down mechanism	The waste container with set-down mechanism ensures ergonomic emptying, even when the vacuumed waste is heavy.

Specifications

Technical data

Power rating in operation (kW)	max. 6
Air flow (l/s/m³/h)	139 / 500
Vacuum (mbar/kPa)	280 / 28
Container capacity (l)	100
Filter area (m²)	2.3
Main filter dust class	M
Sound level (dB(A))	79
Nominal size	61
Accessory nominal size	61 / 51
Weight (kg)	155
Dimensions (L x W x H) (mm)	1220 x 670 x 1530

Equipment

Accessories included with machine, No
Container included, no
Container for dry applications, 6.394-823.0
Dust class, M
Type, Z22
Filter cleaning, Manual
